TL50-Four
Description:

Item No.

TL50-Four series

Stack

Four

Input

12V/24VDC/100-240VAC

Current

12VDC 80mA; 24VDC 40mA

Buzzer

15mA

Color

Red/Orange/Yellow/Green/Blue/White, random combination

Performance

a Revolving; b flash; c jump; d constant color

Electric protection

Protected again reverse polarity

Response time

<10milli seconds

Buzzer frequency

2.7KHz+/-500Hz, 90db

Working temperature ()

-40~50(no buzzer);-20~50(with buzzer)

IP rating

IP67(no buzzer); IP53(with buzzer)

LED life span (H)

100000 hours

Dimension(mm)

Ø50x213.5mm(no buzzer);  Ø50x230mm(with buzzer);

Installation accessory

Foldable base/ fixed plate/ pole with plate

Material

Powerful SMD LED, high transmittance and reinforced ABS and polycarbonate housing, Surface very smooth and flat, high transmittance, unique designed driver, can recognize various performance and maximum five stacks

Feature

Compact and patented design, waterproof. Corrosion proof, oil proof.

Installs directly on machine quickly and easily with prewired or quick-disconnect options no assembly required;

Features a completely self-contained design no controller required;

Display up to 7 colors in a single tower choice of 10 colors in standard brightness and 5 colors in high brightness tower lights;

Allows multiple lights on to be simultaneously

Eliminates false indication from environment, indicator appear grey when off







Approval

CE, FCC
